Application of Plate Heat Exchangers in Fertilizer Production

Plate heat exchangers (PHEs) are widely used in fertilizer production (e.g., urea, compound fertilizers, ammonium phosphate) for processes such as high-temperature reactions, concentration, cooling, and exhaust gas recovery. Their advantages—high heat transfer efficiency, compact design, and easy maintenance—make them ideal for critical stages in fertilizer manufacturing.

Contact Us

Typical Applications of KDP PHEs in Fertilizer Production

Cooling of Ammonium Carbamate Solution in Urea Production

Process Background:

In urea synthesis, high-pressure ammonium carbamate solution (containing NH₃, CO₂, and H₂O) must be rapidly cooled from ~180°C to ~90°C to prevent thermal decomposition.

Role of PHE:

Multi-stage cooling: Pre-cooling with low-temperature carbamate solution followed by deep cooling with chilled water.

High heat transfer efficiency required: Large temperature difference (ΔT≈90°C) and high pressure (≥4 MPa).

Example:

A urea plant uses 316L stainless steel PHEs with 0.7mm plate thickness and a design pressure of 4.5 MPa, achieving a cooling capacity of 2000 kW.

Phosphoric Acid Concentration (Wet Process)

Process Background:

Dilute phosphoric acid (~30% P₂O₅) is concentrated to ~50% P₂O₅. PHEs replace shell-and-tube exchangers to reduce scaling.

Role of PHE:

Falling film evaporation: Phosphoric acid forms a thin film on plate surfaces, heated by steam at ~120°C.

Anti-scaling design: Wide-gap plates minimize clogging.

Example:

A phosphate fertilizer plant uses graphite-modified polypropylene (PP) PHEs (resistant to HF corrosion), extending service life by 3× compared to stainless steel.

Exhaust Gas Recovery in Compound Fertilizer Granulation

Process Background:

Granulation exhaust gases (containing NH₃ and dust at ~80°C) require ammonia recovery and dust removal.

Role of PHE:

Integrated condensation and scrubbing: Exhaust gas contacts chilled water in the PHE, dissolving ammonia into aqueous ammonia.

Corrosion resistance: Trace HF and SO₂ in the gas stream.

Example:

Titanium (Gr.1) PHEs with 6mm plate spacing and spray systems achieve >95% ammonia recovery.

Cooling of Ammonium Nitrate Solution

Process Background:

Ammonium nitrate solution (~80°C) must be cooled to ~30°C to prevent explosive crystallization.

Role of PHE:

Precision cooling with small ΔT: Uses chilled water (ΔT≤5°C).

Explosion-proof design: Fully welded PHEs eliminate gasket leakage risks.

Example:

An ammonium nitrate plant uses 254SMO stainless steel fully welded PHEs, resistant to nitric acid corrosion and ATEX-certified.

Key Factors in Plate Selection

Material Selection (Based on Medium Characteristics)

Medium/ConditionRecommended MaterialReason
Urea ammonium carbamate (high pressure, Cl⁻)316L stainless steelResists chloride stress corrosion
Wet-process phosphoric acid (HF, H₂SO₄)Hastelloy C-276/graphite-PPResists HF and sulfuric acid
Ammonium nitrate (oxidizing acid)254SMO stainless steelHigh molybdenum content, nitric acid resistance
Ammonia condensation (trace HF)Titanium (Gr.1/Gr.2)Halide corrosion resistance, lightweight
Compound fertilizer exhaust (high dust)2205 duplex stainless steelWear + chloride corrosion resistance

Plate Design

High viscosity/solid-containing media (e.g., phosphoric acid slurry):

Wide-gap plates ( ≥6mm flow channels) to prevent clogging.

High-pressure applications (e.g., urea synthesis):

Thickened plates (0.6–1.0mm), laser-welded for reinforcement.

Fouling-prone applications:

Detachable PHEs (for mechanical cleaning), polished surfaces (Ra≤0.5μm).


Sealing and Construction

Gasket selection:

EPDM: For weak acids/alkalis (e.g., ammonia water) below 80°C.

FPM (Viton): For strong acids (HF, HNO₃).

Fully welded construction: For high-pressure/hazardous media (e.g., ammonium nitrate).

KDP Case Studies

Case 1: Concentration Stage in Diammonium Phosphate (DAP) Production

Issue:

Traditional shell-and-tube exchangers scaled heavily, requiring biweekly shutdowns.

Solution:

Titanium plate falling-film evaporator with palladium-coated plates (prevents hydrogen embrittlement).

Design parameters: 120°C, 0.3 MPa, 30% higher concentration efficiency.

Result:

Cleaning intervals extended to 3 months, 15% energy savings.

Case 2: Ammonia Recovery from Compound Fertilizer Exhaust

Original process:

Packed tower absorption, 70% ammonia recovery.

Upgrade:

Titanium PHE + spray system for direct gas-liquid heat exchange.

Plate design: Herringbone corrugation (enhanced turbulence).

Result:

>95% ammonia recovery, compliant emissions.

KDP Maintenance and Optimization

Anti-fouling measures:

Regular CIP cleaning (e.g., 5% HNO₃ for phosphoric acid).

Online ultrasonic descaling (for high solids content).

Corrosion monitoring:

Periodic pitting checks (critical in HF environments).

Safety design:

Ammonium nitrate PHEs must comply with API 521 explosion-proof standards.

Conclusion

Key considerations for PHE selection in fertilizer production:

Corrosivity (material choice depends on HF, H₃PO₄, NH₃, etc.).

Fouling risk (wide-gap plates + removable designs).

Pressure rating (reinforced plates for high-pressure urea stages).

Optimal selection improves energy efficiency and reduces maintenance costs.
